M DİŞ ÖLÇÜSÜ |
P DİŞ ADIMI |
SW ANAHTAR AĞZI |
e KÖŞEGEN |
m KALINLIK max-min |
BİRİM AĞIRLIK gr |
| M3 | 0,50 | 5,5 | 6,01 | 2,4-2,1 | 0,38 |
| M4 | 0,70 | 7,0 | 7,66 | 3,2-2,9 | 0,81 |
| M5 | 0,80 | 8,0 | 8,79 | 4,0-3,7 | 1,23 |
| M6 | 1,00 | 10,0 | 11,05 | 5,0-4,7 | 2,50 |
| M8 | 1,25 | 13,0 | 14,38 | 6,5-6,14 | 5,20 |
| M10 | 1,50 | 17,0 | 18,90 | 8,0-7,64 | 11,60 |
| M12 | 1,75 | 19,0 | 21,10 | 10,0-9,64 | 17,30 |
| M14 | 2,00 | 22,0 | 24,50 | 11,0-10,3 | 25,00 |
| M16 | 2,00 | 24,0 | 26,75 | 13,0-12,3 | 33,30 |
| M18 | 2,50 | 27,0 | 30,15 | 15,0-14,3 | 49,40 |
| M20 | 2,50 | 30,0 | 33,50 | 16,0-14,9 | 64,40 |
| M22 | 2,50 | 32,0 | 35,70 | 18,0-16,9 | 79,00 |
| M24 | 3,00 | 36,0 | 39,00 | 19,0-17,9 | 110,00 |
| M27 | 3,00 | 41,0 | 45,20 | 22,0-20,5 | 165,00 |
| M30 | 3,50 | 46,0 | 50,85 | 24,0-22,5 | 223,00 |
| M33 | 3,50 | 50,0 | 55,35 | 26,0-24,0 | 288,00 |
| M36 | 4,00 | 55,0 | 60,80 | 29,0-27,0 | 393,00 |
| M39 | 4,00 | 60,0 | 66,45 | 31,0-28,5 | 502,00 |
|
Malzeme : 6 KALİTE ÇELİK / 8 KALİTE ÇELİK / 10 KALİTE ÇELİK 304 PASLANMAZ (A2 İNOX) / 316 PASLANMAZ (A4 İNOX) |
|||||
